gc2 24v lithium-ion battery
  • gc2 24v lithium-ion battery
  • 24V Aerial Work Platform Batteries
  • 24V Aerial Working Platform Battery
  • 24V Aerial Work Platform Batteries 24v52ah
  • 24V Aerial Work Platform Batteries 24v67ah
  • 24V Aerial Work Platform Batteries 24v100ah
Aerial Working Platform Battery

GC2 24V Aerial Working Platform Lithium Battery

  • Nominal Voltage

    24V(25.6V)
  • Nominal Capacity

    210Ah
  • Energy

    5.38kWh
  • Cycle Life

    3500+cycles
  • Warranty

    5years
  • Wide temperature

    -20℃~65℃
  • Casing Material

    Steel
  • IP Rating

    IP65
Certification
Customized Requirements

Features for 24V Aerial Working Platform Lithium Battery

Aerial working platform lithium battery manufacturer and factory-Enhance operational efficiency with durable power that meets equipment demands.

Long Life

10 years lifespan, 3500+ cycle life.

Duarble & Worry-Free

0 maintenance, 5 years warranty.

Fast Charging

80% charge in 30 minutes, 20% charge in 5 minutes.

Smart BMS

Lower power force start, 13 protection, power display.

Smart Monitoring

Bluetooth connection, APP monitoring battery status, 4G communciation.

Long-Lasting Power for Aerial Platforms

Battsys aerial work platform lithium batteries have a design lifespan of up to 10 years, three times longer than lead-acid batteries, and come with a 5-year warranty. Upgrading to lithium batteries significantly enhances operational efficiency. They require no maintenance, reducing unplanned downtime. With short charging times and excellent performance under all-weather conditions, they allow for faster completion of tasks.

Applications for Lead-acid to Lithium Battery

Widely used in golf carts, floor cleaner machines, aerial work platforms, forklifts, and marines, among other applications.

Specification for Aerial Working Platform Lithium Battery

Can be customized, providing diversified solutions for various application scenarios.

  • Model
  • Nominal Voltage
  • Nominal Capacity
  • Energy
  • L*W*H
  •  Weight
  •  Continuous Discharge Current
  • Peak Discharge Current@30s
  • Casing Material
  • IP Rating
  • 12V102Ah
  • 12.8V
  • 102Ah
  • 1.31 kWh
  • 12.1x6.8x8.7 inch (308x172x220 mm)
  • 22.9 lbs(10.4 kg)
  • 100A
  • 200A
  • ABS
  • IP67
  • 12V105Ah
  • 12.8V
  • 105Ah
  • 1.34 kWh
  • 10.2x7.1x9.6 inch (260x180x245 mm)
  • 23.8 lbs(10.8 Kg)
  • 100A
  • 200A
  • ABS
  • IP67
  • 12V210Ah
  • 12.8V
  • 210Ah
  • 2.69 kWh
  • 13.6x7.5x9.6 inch (345x190x245 mm)
  • 47.4 lbs(21.5 Kg)
  • 100A
  • 200A
  • ABS
  • IP67
  • 12V210Ah
  • 12.8V
  • 210Ah
  • 2.69 kWh
  • 13.6x7.5x9.6 inch (345x190x245 mm)
  • 47.4 lbs(21.5 Kg)
  • 200A
  • 400A
  • ABS
  • IP67
  • 24V67Ah
  • 25.6V
  • 67Ah
  • 1.72 kWh
  • 20.9x16.9x10.2 inch (260x180x245 mm)
  • 30.2 lbs(13.7 Kg)
  • 70A
  • 140A
  • ABS
  • IP67
  • 24V105Ah
  • 25.6V
  • 105Ah
  • 2.69 kWh
  • 13.6x7.5x9.6 inch (345x190x245 mm)
  • 47.4 lbs(21.5 Kg)
  • 100A
  • 200A
  • ABS
  • IP67
  • 24V210Ah
  • 25.6V
  • 210Ah
  • 5.38 kWh
  • 19.3x13.8x10.2 inch (490x350x260 mm)
  • 110.2 lbs(50.0 Kg)
  • 150A
  • 300A
  • Steel
  • IP65
  • 36V40Ah
  • 38.4V
  • 40Ah
  • 1.54 kWh
  • 10.2x7.1x9.6 inch (260x180x245 mm)
  • 27.1 lbs(12.3 Kg)
  • 40A
  • 80A
  • ABS
  • IP67
  • 48V30Ah
  • 51.2V
  • 30Ah
  • 1.54 kWh
  • 10.2x7.1x9.6 inch (260x180x245 mm)
  • 27.1 lbs(12.3 Kg)
  • 30A
  • 60A
  • ABS
  • IP67
  • 48V105Ah
  • 51.2V
  • 105Ah
  • 5.38 kWh
  • 28.1x10.8x10.4 inch (715x275x265 mm)
  • 99.2 lbs(45.0 Kg)
  • 100A
  • 200A
  • Steel
  • IP65
  • 48V210Ah
  • 51.2V
  • 210Ah
  • 10.75 kWh
  • 29.1x16.9x10.2 inch (740x430x260 mm)
  • 238.1 lbs(108.0 Kg)
  • 150A
  • 300A
  • Steel
  • IP65
  • 48V304Ah
  • 51.2V
  • 304Ah
  • 15.57 kWh
  • 28.3x17.7x10.4 inch (720x450x265 mm)
  • 297.6 lbs(135.0 Kg)
  • 250A
  • 500A
  • Steel
  • IP65
