Battsys 3.2v lifepo4 battery has excellent safety performance; high durability, long cycle life ≥ 20000 times; wide temperature range: charging temperature range 0~60°C, discharging temperature range -20~65°C; super fast charging speed: 3~5C charging, industry leading.
3.2v lifepo4 battery, a lithium ion battery using lithium iron phosphate (LiFePO4) as the cathode material and carbon as the anode material, with a single rated voltage of 3.2V and a charging cut-off voltage of 3.6V~3.65V.
Battsys 3.2v lifepo4 battery has excellent safety performance; high durability, long cycle life ≥ 20000 times; wide temperature range: charging temperature range 0~60°C, discharging temperature range -20~65°C; super fast charging speed: 3~5C charging, industry leading.
Battsys is the best lifepo4 battery manufacturer with high quality, fast global shipping, 3-15 days delivery time, accepts OEM and ODM and lifepo4 battery customization. providing diversified solutions for various application scenarios.
High safety LiFePO4 battery,long cycle life, Fast Charging
Learn More
High rate Discharge, fast charge, long cycle life
Learn MoreBattsys 3.2v lifepo4 cell is mainly used in power storage, special equipment, robotics, AGV, rail transportation, medical equipment, emergency backup, power communication and so on.
Battsys 3.2v lifepo4 battery has the following advantages.
1.Good safety performance, no explosion when punctured, no burning and no explosion when overcharged; safety comes from the stability of the anode material and reliable safety design.
2.Excellent safety performance; High endurance, long cycle life; ≥1.5 years of life.
3.long cycle life;≥ 20000 times
4.Wide temperature range: charging temperature range of 0~60°c,
5.discharging temperature range of-20~65°C;
6.Super fast charging: 3~5C charge, leading in the industry. Using special charger, 1.5C charging 40 minutes can make the battery full.
7. Green: non-toxic, non-polluting, wide source of raw materials, cheap.
1Li-FePO4 battery is 3.2V, the maximum charging voltage is 3.65V, the minimum discharge voltage is 2V, Li-FePO4 battery itself has a certain degree of resistance to over-discharge, even if discharged to 0v, there will not be a problem, occasionally 1-2 times.
3.2V lithium iron phosphate battery is the nominal voltage of the battery cell, but also the discharge platform voltage of the cell. This voltage value represents the average voltage of the process from the beginning of discharge to the termination of discharge of the battery cell at full charge.
The nominal voltage of a 3.2V lithium iron phosphate battery is the voltage of each individual cell. When an individual cell is fully charged, its voltage usually reaches about 3.65V to 3.7V.
LiFePO4 batteries, also known as lithium iron phosphate batteries, have a standard voltage of 12V, which is the voltage achieved by combining multiple individual cells into a battery pack. Each single cell is rated at 3.2V, but the standard voltage of the battery pack is achieved by connecting multiple single cells in series. For example, a 12V LiFePO4 battery pack consists of multiple 3.2V single cells. Such batteries are widely used in many applications, including wind and solar power systems, because of their stability and long life.
The charging method of lithium-ion iron phosphate batteries is different from that of ordinary lithium-ion batteries. In recent years, portable electronic products are lightweight, ultra-small development, portable has begun to use excellent safety performance of lithium iron phosphate battery.
Shallow discharge and shallow charging is the best way for lithium batteries, lithium iron phosphate batteries are characterized by high temperature resistance, not low temperature resistance, high number of cycles of charging and discharging about 3,000-5,000 times, therefore, if you want to improve the service life of lithium iron phosphate batteries, you can start to replenish the battery when the power is close to 20%, charging to 98% of the end of the charging, which will not cause the battery to over-discharge and over-charging, the best for the battery.
The charging of lithium iron phosphate battery packs is recommended to use CCCV charging method, that is, first constant current and then constant voltage. Constant current is recommended to be 0.3C. Constant voltage is recommended to be 3.65. i.e. 0.3C current charging during the constant current process, when the battery voltage reaches 3.65V, 3.65V voltage constant voltage charging is used, and the charging stops when the charging current is lower than 0.1C (or 0.05C), i.e., the battery is already full. When you charge with a scale power supply, it also depends on the charging current, it is recommended not to charge with too high voltage, adjust the voltage to ensure that the charging current is below 0.5C, which is good for the battery.
lifepo4 battery voltage and capacity
Product specifications and performance: the specifications should meet the requirements including voltage and capacity. For example, some manufacturers offer 3.2V lithium iron phosphate batteries with nominal capacities of 3000mAh and 2500mAh, depending on your specific application scenario for battery performance requirements.
Charging method: to understand the standard charging current and charging method of the battery, some batteries support fast charging, with a current of 1.0ItA constant current charging to a single cell voltage (3.65±0.03)v, then switch to constant voltage (3.65±0.03)v charging to a charging current of less than 0.02ItA 1.
Manufacturer reputation and qualification and product certification: choose manufacturers with good reputation and qualification to ensure product quality and after-sales service. Product certification should also be more complete for manufacturers with strength.
Technical support and service: Consider whether the manufacturer can provide the necessary technical support and after-sales service, to see exactly how many years of warranty and warranty period.
Price and supply capacity: Compare the price and supply capacity of different manufacturers to ensure that the price is reasonable and can meet your needs.
